Available As

DOPPSTADT INVENTHOR 6.2

Discover the full range: INVENTHOR Brochure

With the INVENTHOR series, Doppstadt offers a highly versatile solution for processing a wide range of materials and applications. As part of the slow-speed shredder line, these machines utilise high torque to ensure reliable pre-shredding, even of demanding materials. An efficient drivetrain with substantial power reserves, intelligent material feed, and configurable shredding systems ensure consistent and controlled operation.

The INVENTHOR series is based on Doppstadt’s proven single-shaft shredding principle. A key feature of the range is the patented VarioDirect Drive, which is fitted as standard and enables efficient, load-dependent power transmission.

To suit different operational requirements, the INVENTHOR is available as a tracked machine, semi-trailer, or drawbar trailer.

VERSATILITY REDEFINED – SHREDDING WITH DOPPBASKET.

The DoppBasket system enables an even more versatile and efficient use of your Inventhor 6.2. Because using a strainer basket brings you additional advantages:

⚙️Shredding of material to defined target grain size in just one step

⚙️Quick adaptation to changing requirements due to easy removal and assembly of the screen basket

⚙️Self-protective basket system – No fear of impurities thanks to movable basket, which opens if necessary

⚙️Long service life – The screen baskets are made of wear-resistant steel with high sheet thicknesses

⚙️Future-proof and retrofittable, even in existing machines

SHREDDER PACKAGES

Download Brochure

INVENTHOR 6.2	3-AXLE TRAILER	SEMI-TRAILER	TRACK-LAYING CHASSIS
Chassis	Central axle trailer chassis for 80 km/h, as per StVZO	Semi-trailer chassis for 80 km/h, as per StVZO	Track-laying chassis for self-propelled drive, two travel speeds
Overall weight	25,000 kg	27,000 kg	27,000 kg
Length x Width x Height (mm)	14.766 x 2,540 x 3,650	13,314, 2540 x 3,650	13,335 x 2,500 x 3,967
Diesel Engine Type:	MTU 6R1000	MTU 6R1000	MTU 6R1000
Tank Capacity	425 L	425 L	425 L
Output	260 kW , 354 hp	260 kW , 354 hp	260 kW , 354 hp
Optional Extras	“Limiter” oversize return, shredder packages of size M, L, hydraulic drive, rear belt length 7 m, overbelt magnet, auxiliary hopper attachment panels, hopper wedge, misting system, winter package, LED light package	“Limiter” oversize return, shredder packages of size M, L, hydraulic drive, rear belt length 7 m, overbelt magnet, auxiliary hopper attachment panels, hopper wedge, misting system, winter package, LED light package	Limiter” oversize return, shredder packages of size M, L, rear belt length 7 m, overbelt magnet, auxiliary hopper attachment panels, hopper wedge, misting system, winter package, LED light package

INVENTHOR 6.2 PLUS	3-AXLE TRAILER	SEMI-TRAILER	TRACK-LAYING CHASSIS
Diesel Engine Type:	CAT C9.3B	CAT C9.3B	CAT C9.3B
Output	310 kW , 421 hp	Diesel: 310 kW , 421 hp \| Electric: 315 kW , 428 hp	Diesel: 310 kW , 421 hp \| Electric: 315 kW , 428 hp

Request Doyle Brochure

Current Stock

Doppstadt INVENTHOR 6.2Plus

Year of Manufacture: 2025

Enquire Now
